JVC SP-XT9 User Manual

3-48
Loading board(FMU-SM1-11M) (DX-T5)
Block No. [1][3]
Cassette switch board(SLC-S401M)
-Cassette A (Common)
Block No. [1][4]
Head amplifier board(SLC-S401M)
-Cassette A (Common)
Block No. [1][5]
R701 NRSA63J-2R2X MG RESISTOR 2.2 Ω 1/16W J
R703 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R704 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R717 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R731 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R732 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
CN101 QGF0523F1-25W CONNECTOR FFC/FPC (1-25)
CN201 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN451 QGF1016F2-15W CONNECTOR FFC/FPC (1-15)
CN452 QGA2001F2-02X CONNECTOR W-B (1-2)
CN453 QGA2001F2-03X CONNECTOR W-B (1-3)
CN701 QGF1016F2-28W CONNECTOR FFC/FPC (1-28)
CN702 QGF1016F2-10W CONNECTOR FFC/FPC (1-10)
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K454 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K455 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K456 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K501 NQR0502-001X FERRITE BEADS
K710 NQR0022-002X FERRITE BEADS
K732 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K733 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K734 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K735 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K736 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K737 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K738 NQR0022-005X FERRITE BEADS
K744 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K748 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K749 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K750 NQR0022-002X FERRITE BEADS
K752 NQR0022-002X FERRITE BEADS
K754 NQR0022-002X FERRITE BEADS
K756 NQR0022-002X FERRITE BEADS
K758 NQR0022-002X FERRITE BEADS
TH301 NAD0025-103X N THERMISTOR 10k Ω
X301 NAX0741-001X CRYSTAL
X451 NAX0248-001X C OSCILLATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC1 SG-105F3/Z1/ PHOTO SENSER
IC41 NJM4565D IC
IC43 CD4094BE IC
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN41 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN45 QGF1205F1-25 CONNECTOR FFC/FPC (1-25)
CN46 QGF1210G1-09 CONNECTOR FFC/FPC (1-9)
CN47 QGF1210G1-10 CONNECTOR FFC/FPC (1-10)
CN48 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
FW100 QUM024-07A2Z3 PARA RIBON WIRE
P1 QNZ0104-001 POST PIN
SW2 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
Q460 2SC3576-JVC-T TRANSISTOR
Q461 2SC3576-JVC-T TRANSISTOR
Q481 KTA1271/OY/-T TRANSISTOR
Q482 KRC107M-T DIGI TRANSISTOR
Q485 2SB562/C/-T TRANSISTOR
Q486 KTC3199/GL/-T TRANSISTOR
D1 1SR139-400-T2 SI DIODE
D482 1SS133-T2 SI DIODE
D483 1SS133-T2 SI DIODE
D485 MTZJ5.1B-T2 Z DIODE
C449 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C450 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C451 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C452 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C453 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C458 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C459 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C460 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C461 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C462 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C463 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C465 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C466 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C467 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C468 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C469 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C480 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C481 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C484 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C486 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
R371 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R449 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R452 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R453 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R454 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R456 QRE141J-133Y C RESISTOR 13k Ω 1/4W J
R457 QRE141J-133Y C RESISTOR 13k
Ω 1/4W J
R458 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R459 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R460 QRE141J-334Y C RESISTOR 330k
Ω 1/4W J
R461 QRE141J-334Y C RESISTOR 330k
Ω 1/4W J
R462 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R463 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
