JVC SP-XT9 User Manual

3-33
Main board (DX-T7)
Block No. [0][5]
R6516 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R6517 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R6518 QRJ146J-681X UNF C RESISTOR 680 Ω 1/4W J
R6519 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6520 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R6521 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R6522 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R6523 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R6524 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6525 QRE141J-202Y C RESISTOR 2k Ω 1/4W J
R6526 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R6527 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R6528 QRJ146J-681X UNF C RESISTOR 680 Ω 1/4W J
R6529 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6530 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R6531 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R6532 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R6533 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6534 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6535 QRE141J-202Y C RESISTOR 2k Ω 1/4W J
R6536 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
R6537 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
 R6538 QRJ146J-681X UNF C RESISTOR 680 Ω 1/4W J
R6539 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6601 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R6602 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6603 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6604 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
 R6605 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
R6606 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6607 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
 R6608 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
R6701 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6702 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6703 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6704 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6705 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R6706 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R6801 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R6802 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R6803 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
R6804 QRE141J-682Y C RESISTOR 6.8k Ω 1/4W J
 R6805 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R6806 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
R6911 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6912 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R6921 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6922 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R6931 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R6932 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
L6211 QQLZ035-R39 COIL 0.39uH
L6221 QQLZ035-R39 COIL 0.39uH
L6231 QQLZ035-R39 COIL 0.39uH
L6511 QQLZ035-R39 COIL 0.39uH
L6521 QQLZ035-R39 COIL 0.39uH
L6531 QQLZ035-R39 COIL 0.39uH
CN500 QGF1036F1-19 CONNECTOR FFC/FPC (1-19)
CN601 QGB2510K2-20 CONNECTOR B-B (1-20)
CN602 QGF1205C1-19 CONNECTOR FFC/FPC (1-19)
CN603 QGF1205F1-11 CONNECTOR FFC/FPC (1-11)
CN604 QGA2501F1-03 CONNECTOR W-B (1-3)
CN651 QGB2510K2-16 CONNECTOR B-B (1-16)
CN652 QGF1205C1-08 CONNECTOR FFC/FPC (1-8)
CN970 QGB2510J1-04 CONNECTOR B-B (1-4)
FL500 QLF0150-001 FL TUBE
FW500 QUM153-18DGZ4-E FLAT WIRE
J970 QNB0262-001 SPK TERMINAL
S5000 QSW1121-001Z PUSH SW I.M
S5001 QSW1121-001Z PUSH SW I.M
S5002 QSW1121-001Z PUSH SW I.M
S5003 QSW1121-001Z PUSH SW I.M
S5004 QSW1121-001Z PUSH SW I.M
S5005 QSW1121-001Z PUSH SW I.M
S5006 QSW1121-001Z PUSH SW I.M
S5007 QSW1121-001Z PUSH SW I.M
S5008 QSW1121-001Z PUSH SW I.M
 Symbol No. Part No. Part Name Description Local
S5009 QSW1121-001Z PUSH SW I.M
S5010 QSW1121-001Z PUSH SW I.M
S5011 QSW1121-001Z PUSH SW I.M
S5012 QSW1121-001Z PUSH SW I.M
S5013 QSW1121-001Z PUSH SW I.M
S5014 QSW1121-001Z PUSH SW I.M
S5015 QSW1121-001Z PUSH SW I.M
S5016 QSW1121-001Z PUSH SW I.M
S5017 QSW1121-001Z PUSH SW I.M
S5018 QSW1121-001Z PUSH SW I.M
S5019 QSW1121-001Z PUSH SW I.M
S5020 QSW1121-001Z PUSH SW I.M
S5021 QSW1121-001Z PUSH SW I.M
S5022 QSW1121-001Z PUSH SW I.M
S5023 QSW1121-001Z PUSH SW I.M
S5024 QSW1121-001Z PUSH SW I.M
S5025 QSW1121-001Z PUSH SW I.M
S5026 QSW1121-001Z PUSH SW I.M
S5027 QSW1121-001Z PUSH SW I.M
S5028 QSW1121-001Z PUSH SW I.M
S5029 QSW1121-001Z PUSH SW I.M
S5030 QSW1121-001Z PUSH SW I.M
S5031 QSW1121-001Z PUSH SW I.M
S5032 QSW1121-001Z PUSH SW I.M
S5033 QSW1121-001Z PUSH SW I.M
S5034 QSW1121-001Z PUSH SW I.M
SP500 GV40205-004A IC HOLDER
 Symbol No. Part No. Part Name Description Local
IC760 SN74AHCT08NS-X IC
IC770 MN101C49GFS1 MASK ROM
IC771 BR24L02F-W-X IC
IC800 RC4558D-X IC
IC801 RC4558D-X IC
IC810 CD4066BM-X IC
IC820 LC75342M-X IC
IC830 RC4558D-X IC
IC850 M65851FP IC
IC860 JCV8011-X IC
IC870 LC75341M-X IC
IC880 LC75341M-X IC
IC881 RC4558D-X IC
IC901 RC4580ID-X IC
Q7000 KTC3199/GL/-T TRANSISTOR
Q7010 KTC3199/GL/-T TRANSISTOR
Q7080 KRC107S-X DIGI TRANSISTOR
Q7081 KRC111S-X TRANSISTOR
Q7788 KRA102S-X DIGI TRANSISTOR
Q7794 KRA102S-X DIGI TRANSISTOR
Q7798 KRA102S-X DIGI TRANSISTOR
Q8000 2SD2114K/VW/-X TRANSISTOR
Q8030 KTC3875/YG/-X SI TRANSISTOR
Q8031 KTC3875/YG/-X SI TRANSISTOR
Q8032 KTC3875/YG/-X SI TRANSISTOR
Q8040 2SD2114K/VW/-X TRANSISTOR
Q8070 2SD2114K/VW/-X TRANSISTOR
Q8071 2SD2114K/VW/-X TRANSISTOR
Q8080 2SD2114K/VW/-X TRANSISTOR
Q8081 2SD2114K/VW/-X TRANSISTOR
Q8100 2SD2114K/VW/-X TRANSISTOR
Q8130 KTC3875/YG/-X SI TRANSISTOR
Q8131 KTC3875/YG/-X SI TRANSISTOR
Q8132 KTC3875/YG/-X SI TRANSISTOR
Q8140 2SD2114K/VW/-X TRANSISTOR
Q8170 2SD2114K/VW/-X TRANSISTOR
Q8171 2SD2114K/VW/-X TRANSISTOR
Q8180 2SD2114K/VW/-X TRANSISTOR
Q8211 KRC104S-X TRANSISTOR
Q8212 KRC104S-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
