3-26
Main board (DX-T9)
Block No. [0][2]
R5005 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5006 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5007 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R5008 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R5009 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5010 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R5011 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R5012 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R5013 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R5014 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5015 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5016 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5017 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5018 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
R5019 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R5020 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R5021 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5022 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5023 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R5024 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5025 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R5026 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R5027 QRE141J-152Y C RESISTOR 1.5k Ω 1/4W J
R5028 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R5029 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5030 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5035 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R5036 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R5037 QRE141J-560Y C RESISTOR 56 Ω 1/4W J
R5038 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5039 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5040 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5041 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5042 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R5043 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R5044 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
R5045 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R5046 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
L3401 QQLZ035-R39 COIL 0.39uH
L3501 QQLZ035-R39 COIL 0.39uH
L3601 QQLZ035-R39 COIL 0.39uH
L4101 QQLZ035-R39 COIL 0.39uH
L4201 QQLZ035-R39 COIL 0.39uH
L4601 QQLZ035-R39 COIL 0.39uH
L4701 QQLZ035-R39 COIL 0.39uH
CN301 QGB2510K2-20 CONNECTOR B-B (1-20)
CN302 QGF1205C1-19 CONNECTOR FFC/FPC (1-19)
CN303 QGF1205F1-11 CONNECTOR FFC/FPC (1-11)
CN304 QGA2501F1-03 CONNECTOR W-B (1-3)
CN401 QGB2510K2-16 CONNECTOR B-B (1-16)
CN402 QGF1205C1-08 CONNECTOR FFC/FPC (1-8)
CN500 QGF1036F1-19 CONNECTOR FFC/FPC (1-19)
CN990 QGB2510J1-06 CONNECTOR B-B (1-6)
FL500 QLF0150-001 FL TUBE
FW401 QUM154-10Z4Z4-E FLAT WIRE
FW500 QUM153-18DGZ4-E FLAT WIRE
J990 QNB0263-001 SPK TERMINAL
S5000 QSW1121-001Z PUSH SW I.M
S5001 QSW1121-001Z PUSH SW I.M
S5002 QSW1121-001Z PUSH SW I.M
S5003 QSW1121-001Z PUSH SW I.M
S5004 QSW1121-001Z PUSH SW I.M
S5005 QSW1121-001Z PUSH SW I.M
S5006 QSW1121-001Z PUSH SW I.M
S5007 QSW1121-001Z PUSH SW I.M
S5008 QSW1121-001Z PUSH SW I.M
S5009 QSW1121-001Z PUSH SW I.M
S5010 QSW1121-001Z PUSH SW I.M
S5011 QSW1121-001Z PUSH SW I.M
S5012 QSW1121-001Z PUSH SW I.M
S5013 QSW1121-001Z PUSH SW I.M
S5014 QSW1121-001Z PUSH SW I.M
S5015 QSW1121-001Z PUSH SW I.M
S5016 QSW1121-001Z PUSH SW I.M
S5017 QSW1121-001Z PUSH SW I.M
S5018 QSW1121-001Z PUSH SW I.M
 Symbol No. Part No. Part Name Description Local
S5019 QSW1121-001Z PUSH SW I.M
S5020 QSW1121-001Z PUSH SW I.M
S5021 QSW1121-001Z PUSH SW I.M
S5022 QSW1121-001Z PUSH SW I.M
S5023 QSW1121-001Z PUSH SW I.M
S5024 QSW1121-001Z PUSH SW I.M
S5025 QSW1121-001Z PUSH SW I.M
S5026 QSW1121-001Z PUSH SW I.M
S5027 QSW1121-001Z PUSH SW I.M
S5028 QSW1121-001Z PUSH SW I.M
S5029 QSW1121-001Z PUSH SW I.M
S5030 QSW1121-001Z PUSH SW I.M
S5031 QSW1121-001Z PUSH SW I.M
S5032 QSW1121-001Z PUSH SW I.M
S5033 QSW1121-001Z PUSH SW I.M
S5034 QSW1121-001Z PUSH SW I.M
SP500 GV40205-004A IC HOLDER
 Symbol No. Part No. Part Name Description Local
IC760 SN74AHCT08NS-X IC
IC770 MN101C49GFS1 MASK ROM
IC771 BR24L02F-W-X IC
IC800 RC4558D-X IC
IC801 RC4558D-X IC
IC810 CD4066BM-X IC
IC820 LC75342M-X IC
IC830 RC4558D-X IC
IC850 M65851FP IC
IC860 JCV8011-X IC
IC870 LC75341M-X IC
IC880 LC75341M-X IC
IC881 RC4558D-X IC
IC901 RC4580ID-X IC
Q7000 KTC3199/GL/-T TRANSISTOR
Q7010 KTC3199/GL/-T TRANSISTOR
Q7080 KRC107S-X DIGI TRANSISTOR
Q7081 KRC111S-X TRANSISTOR
Q7788 KRA102S-X DIGI TRANSISTOR
Q7794 KRA102S-X DIGI TRANSISTOR
Q7798 KRA102S-X DIGI TRANSISTOR
Q8000 2SD2114K/VW/-X TRANSISTOR
Q8030 KTC3875/YG/-X SI TRANSISTOR
Q8031 KTC3875/YG/-X SI TRANSISTOR
Q8032 KTC3875/YG/-X SI TRANSISTOR
Q8040 2SD2114K/VW/-X TRANSISTOR
Q8070 2SD2114K/VW/-X TRANSISTOR
Q8071 2SD2114K/VW/-X TRANSISTOR
Q8080 2SD2114K/VW/-X TRANSISTOR
Q8081 2SD2114K/VW/-X TRANSISTOR
Q8100 2SD2114K/VW/-X TRANSISTOR
Q8130 KTC3875/YG/-X SI TRANSISTOR
Q8131 KTC3875/YG/-X SI TRANSISTOR
Q8132 KTC3875/YG/-X SI TRANSISTOR
Q8140 2SD2114K/VW/-X TRANSISTOR
Q8170 2SD2114K/VW/-X TRANSISTOR
Q8171 2SD2114K/VW/-X TRANSISTOR
Q8180 2SD2114K/VW/-X TRANSISTOR
Q8211 KRC104S-X TRANSISTOR
Q8212 KRC104S-X TRANSISTOR
Q8260 KTC3199/GL/-T TRANSISTOR
Q8524 KTC1027/OY/-T TRANSISTOR
Q8900 KRA104S-X DIGI TRANSISTOR
Q9001 2SD2114K/VW/-X TRANSISTOR
Q9002 2SD2114K/VW/-X TRANSISTOR
Q9003 KRC111S-X TRANSISTOR
Q9004 KTA1504/YG/-X SI TRANSISTOR
Q9100 KRA111S-X D. TRANSISTOR
Q9101 2SD2114K/VW/-X TRANSISTOR
Q9102 2SD2114K/VW/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
