JVC TH-D5 User Manual

33
Center unit (XV-THD60/XV-THD50/XV-
THD5/XV-THD4)
Output power
Front/Surround:
For XV-THD60/XV-THD50
: 200 W per channel, RMS at
3 Ω at 1 kHz, with 10 % total harmonic distortion.
For XV-THD5
: 180 W per channel, RMS at 3 Ω at 1 kHz,
with 10 % total harmonic distortion.
For XV-THD4
: 167 W per channel, RMS at 3 Ω at 1 kHz,
with 10 % total harmonic distortion.
Center:
For XV-THD60/XV-THD50
: 200 W, RMS at 3 Ω at
1 kHz, with 10 % total harmonic distortion.
For XV-THD5
: 180 W, RMS at 3 Ω at 1 kHz, with 10 %
total harmonic distortion.
For XV-THD4
: 167 W, RMS at 3 Ω at 1 kHz, with 10 %
total harmonic distortion.
Subwoofer:
For XV-THD60/XV-THD50
: 200 W, RMS at 3 Ω at
100 Hz, with 10 % total harmonic distortion.
For XV-THD5
: 200 W, RMS at 3 Ω at 100 Hz, with 10 %
total harmonic distortion.
For XV-THD4
: 167 W, RMS at 3 Ω at 100 Hz, with 10 %
total harmonic distortion.
Audio section
Digital Input*
1
DIGITAL IN
OPTICAL: –21 dBm to –15 dBm (660 nm
±30 nm)
COAXIAL*
2
:0.5V(p-p)/75Ω
Video section
Video System: NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video Output Level (VIDEO OUT)
Composite video: 1.0 V(p-p)/75 Ω
S-video (Y): 1.0 V(p-p)/75 Ω
(C): 0.286 V(p-p)/75 Ω
Component (Y): 1.0 V(p-p)/75 Ω
(P
B/PR):0.7V(p-p)/75Ω
Video Input Sensitivity/Impedance
(VIDEO IN)
Composite: 1.0 V(p-p)/75 Ω
S-video (Y): 1.0 V(p-p)/75 Ω
(C): 0.286 V(p-p)/75 Ω
HDMI
HDMI Input (VIDEO 1 IN)*
2
:
PASS THROUGH (up to
225 MHz)
HDMI Output (MONITOR OUT):
480p/720p/1080i
USB storage
USB Specification: Compatible with USB 2.0 Full-
Speed
Compatible Device: Mass Storage Class
Compatible File System: FAT16, FAT32
Bus Power Supply: Max. 500 mA
Tuner section
Tuner Range
FM: 87.5 MHz to 108.0 MHz
AM: 530 kHz to 1 710 kHz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 160 W (during operation)
1.3 W (in standby mode)
Dimensions (W
× H × D):
435 mm
× 115 mm × 270 mm
(17-3/16 inches
× 4-3/8 inches × 10-11/16 inches)
Mass: 6.8 kg (15.0 lbs)
*
1
Corresponding to Linear PCM, Dolby Digital, and DTS
Digital Surround (with sampling frequency — 32 kHz,
44.1 kHz, 48 kHz)
*
2
Only for XV-THD60
Subwoofer
For SP-THD6W (TH-D60)
Type: Bass-Reflex Type
Speaker: 20 cm (7-7/8 inches) cone
× 1
Power Handling Capacity: 200 W
Impedance: 3 Ω
Frequency Range: 28 Hz to 200 Hz
Sound Pressure Level: 74 dB/W
• m
Dimensions (W
× H × D):
353.5 mm
× 351 mm × 248 mm
(13-15/16 inches
× 13-7/8 inches × 9-13/16 inches)
Mass: 8.5 kg (18.8 lbs)
For SP-THD5W (TH-D50/TH-D5/TH-D4)
Type: Bass-Reflex Type
Speaker: 16 cm (6-5/16 inches) cone
× 1
Power Handling Capacity: 200 W
Impedance: 3 Ω
Frequency Range: 30 Hz to 200 Hz
Sound Pressure Level: 74 dB/W
• m
Dimensions (W × H × D):
353.5 mm
× 351 mm × 174 mm
(13-15/16 inches
× 13-7/8 inches × 6-7/8 inches)
Mass: 6.3 kg (13.9 lbs)
Specifications
References
Body_TH-D456[JC].fm Page 33 Friday, February 23, 2007 8:55 PM

JVC TH-D5 Specifications

General

Equalizer	Yes
RMS rated power	810 W
Audio output channels	5.0 channels
Center speaker RMS power	130 W
Optical disc player type	DVD player
Weight	6800 g
Dimensions (WxDxH)	435 x 115 x 270 mm
Power requirements	AC 230V, 50Hz
Remote control type	Multi-Brand Remote
Media types supported	DVD-Audio, DVD-Video, DVD-RW, DVD-R (VR/Video), +RW/+R (Video), CD / CD-R/RW, SVCD / VCD; MP3, WMA, WAV (CD-R/RW, DVD-R/RW, USB), JPEG Digital Still, MPEG-1/MPEG-2, MPEG-4, DivX(R)
Surround speaker weight	850 g
Surround speaker dimensions (WxHxD)	98.5 x 214.5 x 93.5 mm
USB version	2.0
SCART ports quantity	2
Power consumption (standby)	1 W
Power consumption (typical)	160 W

Weight and Dimensions

Subwoofer weight	6300 g
Rear speaker weight	2000 g
Subwoofer dimensions (WxDxH)	353.5 x 351 x 174 mm
Dimensions rear speaker (W x D x H)	435 x 99 x 93.5 mm
