4.1 Inputs
4.1.1 
STO
Inputs
Status 0 Status 1
UL [V] IL [mA] UH [V] IH [mA]
max. 5 55 30 55
min. -3 notdened 15 5
Table 7: Specication of the STO inputs
The maximum short-term starting current of the input is limited to 0.6 mA.
4.1.2 STO with OSSD signals
Theltertimedependsontheminimuminputvoltageandcanbespeciedasfollows:
Input voltage [V] OSSD pulse width [ms]
15 0.08
18 0.5
20 1.0
24 1.4
30 1.8
Table 8: STO with OSSD signals
4.1.3 
TheinputsoftheSBCfunctionarespeciedasfollowsaccordingtoIEC61131-2type1:
SBC
Inputs
Status 0 Status 1
UL [V] IL [mA] UH [V] IH [mA]
max. 5 15 30 15
min. -3 notdened 15 2
Table 9: Specication of the SBC inputs
The maximum short-term starting current of the input is limited to 30 mA.
Attention
Consistency check
Since a consistency check of the input signals takes place, a slew rate of
> 1 V/ms must be available at a status change.
4.1.4 SBC with OSSD signals
Theltertimefortheentirevoltagerangeisatleast1ms.
22
DESCRIPTION OF THE TERMINALS
