KEB COMBIVERT H6 User Manual

9
GLOSSARY
Glossary
0V Earth-potential-free common point
1ph 1-phase mains
3ph 3-phase mains
AC AC current or voltage
AFE From 07/2019 AIC replaces the pre-
vious name AFE
AFElter From07/2019AIClterreplacesthe
previousnameAFElter
AIC Active Infeed Converter
AIClter Filter for Active Infeed Converter
Application The application is the intended use
of the KEB product
ASCL Asynchronous sensorless closed
loop
Auto motor
ident.
Automaticallymotoridentication;
calibration of resistance and induc-
tance
AWG American wire gauge
B2B Business-to-business
BiSS Open source real-time interface for
sensors and actuators (DIN 5008)
CAN Fieldbus system
CDM Complete drive module including
auxiliary equipment (control cabinet)
COMBIVERT KEB drive converters
COMBIVIS KEB start-up and parameterizing
software
Customer The customer has purchased a KEB
product from KEB and integrates the
KEB product into his product (cus-
tomer product) or resells the KEB
product (dealer)
DC DC current or voltage
DI Demineralized water, also referred to
as deionized (DI) water
DIN German Institut for standardization
DS 402 CiADS402-CANdeviceprolefor
drives
EMC Electromagnetic compatibility
Emergency
stop
Shutdown of a drive in emergency
case (not de-energized)
Emergency
switching off
Switching off the voltage supply in
emergency case
EN European standard
Encoder emu-
lation
Software-generated encoder output
End customer The end customer is the user of the
customer product
Endat Bidirectional encoder interface of the
company Heidenhain
EtherCAT Real-time Ethernet bus system of the
company Beckhoff
Ethernet Real-timebussystem-denespro-
tocols, plugs, types of cables
FE Functional earth
FSoE Functional Safety over Ethernet
FU Drive converter
GND Reference potential, ground
GTR7 Braking transistor
HFlter Highfrequencyltertothemains
Hiperface Bidirectional encoder interface of the
company Sick-Stegmann
HMI Human machine interface (touch
screen)
HSP5 Fast, serial protocol
HTL Incremental signal with an output
voltage (up to 30V) -> TTL
IEC International standard
IP xx Degree of protection (xx for level)
KEB product The KEB product is subject of this
manual
KTY Silicium temperature sensor (pola-
rized)
Manufacturer The manufacturer is KEB, unless
otherwisespecied(e.g.asma-
nufacturer of machines, engines,
vehicles or adhesives)
MCM American unit for large wire cross
sections
Modulation Means in drive technology that the
power semiconductors are controlled
MTTF Mean service life to failure
NN Sea level
OC Overcurrent
OH Overheat
OL Overload
OSSD Outputsignalswithchingdevice;-an
output signal that is checked in regu-
lar intervals on its shutdown. (safety
technology)
PDS Power drive system incl. motor and
measuring probe
PE Protective earth
PELV Protective Extra Low Voltage
PFD Term used in the safety technology
(EN 61508-1...7) for the size of error
probability
PFH Term used in the safety technology
(EN 61508-1...7) for the size of error
probability per hour
