Keba KeControl CP 50 Series User Manual

CP 503/A, CP 505/A,D,K, CP 507/
A,C
Technical data
Project engineering manual V1.06
77
© KEBA 2021
12.5 Interfaces
USB interfaces
Quantity: 1
Type: USB 3.0 (SuperSpeed)
Output current: Max. 900 mA
EtherCAT interfaces
Quantity: 1
Plug type: RJ45
Data transmission rate: 100 Mbit/s
Ethernet interfaces
Quantity: 2
Plug type: RJ45
Data transmission rate: 10/100/1,000 Mbit/s
Graphic interfaces
Quantity: 1
Type: DVI-D
Plug: DVI-I
Boot drive interface
Quantity: 1
Type: microSD
CAN interfaces
Quantity: 1
Data transmission rate:
125 kbit/s bis 1 Mbit/s (configurable via soft-
ware)
Terminating resistor: Yes (configurable via DIP switch on front)
Galvanic isolation: No
Connection technology: Industrial Mini I/O plug type 2
Transmission medium: Shielded cable
Serielle interfaces
Type:
RS-232-C / RS-485-A / RS-422-A (setting via
software)
Connection technology: Indurstrial Mini I/O plug type 2
Data transmission rate:
1,200 bit/s to 115,200 bit/s (setting via soft-
ware)
Galvanic isolation: No
Transmission medium: Shielded cable, 100 Ω to 120 Ω
Cable length:
Max. 100 m at 115,200 bit/s (for RS-485-A /
RS-422-A)
