Need help?Do you have a question about the Keithley 2260B-80-13 and is the answer not in the manual?
General| Output Voltage Range | 0 to 80 V |
|---|---|
| Output Current Range | 0 to 13 A |
| Power Rating | 1040 W |
| Temperature Coefficient | 100 ppm/°C |
| Voltage Programming Accuracy | 0.03% + 10 mV |
| Load Regulation | 0.01% + 2 mV |
| Line Regulation | 0.01% + 2 mV |
| Interface | USB, GPIB |
| Operating Temperature Range | 0 to 40 °C |
| Storage Temperature Range | -40 to 70 °C |
The primary document for operating and maintaining the 2260B Series power supplies.
Explanation of standard safety symbols used in the manual and on the instrument.
General precautions and guidelines for safe operation and handling of the instrument.
Introduction to the 2260B series, including model lineup and key features.
Detailed list of performance, features, and interface capabilities of the 2260B series.
Explanation of the fundamental operating principles of the 2260B power supplies.
Explanation of constant current (CC) and constant voltage (CV) operating modes.
Procedures for setting up the 2260B, including filter installation.
Steps for powering on the 2260B and initial display behavior.
Overview of fundamental operations like setting OVP/OCP, CV, CC modes, display modes, panel lock, and remote sense.
Steps for setting the overvoltage (OVP) and overcurrent (OCP) protection levels.
Procedure for configuring the power supply to operate in Constant Voltage (CV) mode.
Procedure for configuring the power supply to operate in Constant Current (CC) mode.
Using remote sense to compensate for voltage drops across load cables.
Connecting multiple 2260B units in parallel for increased power output.
Connecting multiple 2260B units in series for increased output voltage.
Basic operations for connecting and using 2260B units in series or parallel.
Overview of parallel operation using a master-slave configuration.
Wiring diagrams and steps for connecting 2260B units in parallel.
Configuration and operation steps for master-slave parallel setups.
Overview of series operation using a master-slave configuration.
Wiring diagrams and steps for connecting 2260B units in series.
Configuration and operation steps for master-slave series setups.
Overview of configuration settings: Normal Function, USB/GPIB, LAN, Power ON, Calibration, System.
Detailed table of configuration settings, their parameters, and ranges.
Settings that can only be configured during power-up, such as CV/CC control and Master/Slave modes.
Overview of analog control options for voltage, current, and power switch.
Description of the MIL-26 pin connector and its pin assignments for remote control.
Using external voltage to control the output voltage of the 2260B.
Using external voltage to control the output current of the 2260B.
Using external resistance to control the output voltage of the 2260B.
Using external resistance to control the output current of the 2260B.
Support for monitoring output voltage, current, operation, and alarm status remotely.
Using the MIL-26 connector to monitor voltage (VMON) and current (IMON) output.
Detailed technical specifications for the 2260B series power supplies.
