Long Integration Measurements 4-13
NOTE Setting the trigger level and/or the trigger range may cause “LONG INT TRIG NOT
DETECTED” to appear.
SCPI programming
The commands for long integration measurements are summarized in Table 4-2 (a listing fol-
lowing the table contains specific command notes). “Programming examples” on page 4-19
demonstrate how to use these commands.
Table 4-2
SCPI commands — long integration measurements
Command Description Default
:SENSe[1] SENSe subystem for channel
#1 (battery channel):
:FUNCtion “LINTegration” Select long integration measurement function. VOLT
:LINTegration Long integration conf
iguration:
:TIME <NRf> Set integration time (in sec): X to 60 (where X
is 0.850 for 60Hz, or 0.840 for 50Hz).
1
:AUTO Integration time set automatically.
:TLEVel <NRf> Path to set trigger level feature:
[:AMP] <NRf> Set trigger level (in amps) for 5A range: 0–5
(5mA resolution).
0.0
:ONE <NRf> Set trigger level (in amps) for 1A trigger level
range: 0–1 (1mA resolution).
0.0
:MILLiamp <NRf> Set trigger level (in amps) for 100mA range:
0–0.1 (0.1mA resolution).
0.0
:HALFamp <NRf> Model 2306-PJ only — set trigger level (in amps) for
50
0mA range: 0-500mA (0.5mA resolution)
0.0
:HUNDred <NRf> Model 2306-PJ only — set trigger level (in amps) for
10
0mA range: 0-100mA (0.1mA resolution)
0.0
:TEN <NRf> Model 2306-PJ only — set trigger level (in amps) for
10
mA range: 0-10mA (0.01mA resolution)
0.0
:RANGe <NRf> Model 2306, 2306-VS or 2306-PJ when on 5A current
r
ange. Set trigger level range (100mA, 1A, or
5A). The parameter <NRf> sent with this com-
mand causes the trigger to be
set with the trigger
level setting of MILL, ONE, or AMP. Queries
receive responses of 0.1, 1.0, or 5.0 accordingly.
In other words, if a value of 2.0A is sent with the
command, a value of 5A will be returned as a
response to a query.
5A
