7½ Digit Multimeter User's Manual Section 2: Using the front-panel interface
DMM7510-900-01 Rev. B / May 2015 2-11
SECONDARY swipe screen
The SECONDARY swipe screen allows you to display the results of two measurements on the
front-panel display.
To start displaying secondary measurements, select the Second Function and select Secondary
Measure. Secondary measurements are only available in Continuous Measurement Mode and
Manual Trigger Mode. Refer to "Display results of two measure functions" in the Model DMM7510
Reference Manual.
Figure 8: SECONDARY swipe screen
Depending on the selected functions, a relay may click when the instrument switches between the
measurement types. Leaving secondary measurements on for extended periods may shorten the life
of the relays.
