Digital Audio Performance| frequency response (playback mode) | 8 Hz ~ 20 kHz, ± 1 dB |
|---|---|
| signal to noise ratio (playback mode) | More than 100 dB |
| wow & flutter | Less than unmeasurable limit |
Analog Specifications| analog input sensitivity / input impedance | 0.5V / 22 kΩ or more |
|---|---|
| analog output level/output impedance | 2.0 V / Less than 2 kΩ |
| headphone output | 15 mW/32 Ω load |
Digital Input/Output| digital input coaxial | 0.5 Vp-p / 75 Ω |
|---|---|
| digital input optical | - 15 dBm ~ - 21 dBm |
| digital output optical | - 15 dBm ~ - 21 dBm |
General Specifications| power consumption | 17 W |
|---|---|
| dimensions width | 440 mm (17 - 5 / 16”) |
| dimensions height | 94 mm (3 - 11 / 16”) |
| dimensions depth | 300 mm (11 - 13 / 16”) |
Weight| weight | 3.55 kg (7.9 lb) |
|---|
