ENGLISH
19
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
SUBWOOFER SET ON
:Turns on the subwoofer output.;
OFF
:Cancels.
FADER
(Not applicable if 3-way crossover is selected.)
R15
to
F15
(
0
):Adjusts the rear and front speaker output balance.
BALANCE L15
to
R15
(
0
):Adjusts the left and right speaker output balance.
VOLUME OFFSET –15
to
+6
(
0
):Preset the initial volume level of each source. (Before
adjustment, select the source you want to adjust.)
SOUND EFFECT
SOUND RECNSTR
(Sound
reconstruction)
(Not applicable for TUNER source and AUX source.)
ON
:Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are
lost in audio data compression.;
OFF
:Cancels.
SPACE ENHANCE
(Not applicable for TUNER source.)
SMALL
/
MEDIUM
/
LARGE
:Virtually enhances the sound space.;
OFF
:Cancels.
SND REALIZER LEVEL1
/
LEVEL2
/
LEVEL3
:Virtually makes the sound more
realistic.;
OFF
:Cancels.
STAGE EQ LOW
/
MIDDLE
/
HIGH
:Virtually adjust the sound position heard
from the speakers.;
OFF
:Cancels.
DRIVE EQ ON
: Boosts the frequency to reduce the noise heard from outside the
car or running noise of the tyres.;
OFF
:Cancels.
SPEAKER SIZE
Depending on the crossover type you have selected
(
5
)
, 2-way
crossover or 3-way crossover setting items will be shown.
(
19, 20
)
By default, 2-way crossover type is selected.
X ‘ OVER
• [
SUB-W LEVEL
] is selectable only if [
SUBWOOFER SET
] is set to [
ON
].
Crossover settings
Below are the available setting items for 2-way crossover and 3-way
crossover.
SPEAKER SIZE
Selects according to the connected speaker size for optimum
performance.
•
The frequency and slope settings are automatically set for the
crossover of the selected speaker.
•
If [
NONE
] is selected for [
TWEETER
] of [
FRONT
], [
REAR
] and [
SUBWOOFER
] for
[
SPEAKER SIZE
], the [
X ‘ OVER
] setting of the speaker is not available.
X ‘ OVER
[
FRQ
]/ [
F - HPF FRQ
]/ [
R - HPF FRQ
]/ [
SW LPF FRQ
]/ [
HPF FRQ
]/ [
LPF FRQ
]:
Adjusts the crossover frequency for the selected speakers (high pass
filter or low pass filter).
• If [
THROUGH
] is selected, all signals are sent to the selected speakers.
[
F - HPF SLOPE
]/ [
R - HPF SLOPE
]/ [
SW LPF SLOPE
]/ [
HPF SLOPE
]/ [
LPF SLOPE
]/
[SLOPE]:
Adjusts the crossover slope.
• Selectable only if a setting other than [
THROUGH
] is selected for the
crossover frequency.
[
SW LPF PHASE
]/
[PHASE]:
Selects the phase of the speaker output to be in line with the other
speaker output.
[
GAIN LEFT
]/ [
GAIN RIGHT
]/ [
F - HPF GAIN
]/ [
R - HPF GAIN
]/ [
SW LPF GAIN
]/ [
GAIN
]:
Adjusts the output volume of the selected speaker.
The following items is selectable only if [
SUBWOOFER SET
] is set to [
ON
]:
– [
SUBWOOFER
]/ [
WOOFER
] of [
SPEAKER SIZE
]
– [
SUBWOOFER LPF
]/ [
WOOFER
] of [
X ‘ OVER
]
JS_KWD_DPX_5000BT_MN_EN_1.indd 19JS_KWD_DPX_5000BT_MN_EN_1.indd 19 30/10/2015 10:37:32 AM30/10/2015 10:37:32 AM
