AUDIO SETTINGS
2-way crossover setting items
SPEAKER SIZE
FRONT SIZE
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM /
4×6
/ 5×7 / 6×8 / 6×9 / 7×10
TWEETER
SMALL / MIDDLE / LARGE / NONE (not connected)
REAR 8  CM / 10  CM / 12  CM / 13  CM / 16 CM / 17  CM / 18  CM / 4×6 / 5×7 / 6×8 /
6×9
/ 7×10 / NONE (not connected)
SUBWOOFER 16CM / 20CM / 25CM / 30CM / 38CM OVER / NONE (not connected)
X ' OVER
TWEETER FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ /
8KHZ
/ 10KHZ / 12.5KHZ
GAIN LEFT
–8 to 0
GAIN RIGHT
–8 to 0
FRONT HPF F - HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ / 120HZ / 150HZ / 180HZ / 220HZ / 250HZ/
THROUGH
F - HPF SLOPE
–6DB / –12DB / –18DB / –24DB
F - HPF GAIN
–8 to 0
REAR HPF R - HPF FRQ
(Refer FRONT HPF settings above.) R - HPF SLOPE
R - HPF GAIN
SUBWOOFER
LPF
SW LPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ
/ 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
SW LPF SLOPE
–6DB / –12DB / –18DB / –24DB
SW LPF PHASE
REVERSE (180°)/ NORMAL (0°)
SW LPF GAIN –8 to 0
3-way crossover setting items
SPEAKER SIZE
TWEETER
SMALL / MIDDLE / LARGE
MID RANGE
8CM / 10CM / 12CM / 13CM / 16CM / 17CM / 18CM / 4×6 / 5×7 / 6×8 /
6×9
WOOFER
16CM / 20CM / 25CM / 30CM / 38CM OVER / NONE (not connected)
X ' OVER
TWEETER HPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ
/ 12.5KHZ
F - HPF SLOPE
–6DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –8 to 0
MID RANGE HPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ / 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
HPF SLOPE
–6DB / –12DB
LPF FRQ
1KHZ / 1.6KHZ / 2.5KHZ / 4KHZ / 5KHZ / 6.3KHZ / 8KHZ /
10KHZ
/ 12.5KHZ / THROUGH
LPF SLOPE
–6DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –8 to 0
WOOFER LPF FRQ
30HZ / 40HZ / 50HZ / 60HZ / 70HZ / 80HZ / 90HZ /
100HZ / 120HZ / 150HZ / 180HZ / 220HZ / 250HZ /
THROUGH
SLOPE
–6DB / –12DB
PHASE
REVERSE (180°)/ NORMAL (0°)
GAIN –8 to 0
