Kenwood KVC-1000 User Manual

3Adjusting the Picture Quality
[BRT]
Touch [ 3 ] for a brighter screen.
Touch [ 2 ] for a darker screen.
[TIN]
Touch [ 3 ] for a stronger green level.
Touch [ 2 ] for a stronger red level.
[COL]
Touch [ 3 ] for a deeper colour.
Touch [ 2 ] for a paler colour.
[CONT]
Touch [ 3 ] for less contrast.
Touch [ 2 ] for stronger contrast.
[BLK]
Touch [ 3 ] for less blackness.
Touch [ 2 ] for a stronger black level.
• The [ TIN ] and [ COL ] cannot be adjusted for the
navigation screen or the graphic screens (Audio
source control, etc.).
• The [ TIN ] cannot be adjusted for the picture of
PAL/SECAM.
• Separate picture quality settings can be stored for
the television, video 1, video 2, graphic screens and
navigation screens and for day and night use.
3Turning the Dimmer Function On/Off
Touch [ ON ] or [ OFF ] to switch the function on and
off.
: Switch head light ON, and switch to
nighttime viewing screen picture
: Leave the set in nighttime viewing screen
When adjusting nighttime picture quality, switch this
function ON and switch head lights ON.
3Switching to the Angle Control Screen
Touch [ ANGLE ] to switch to the angle control
screen.
3Ending the Screen Control Screen
Touch [ OK ].
NOTE
NOTE
English
7
3Adjusting the Angle Position [ANGLE]
Each time you touch [ 3 ], the monitor slants back
one step.
Each time you touch [ 2 ], the monitor slants forward
one step
The angle can be adjusted in 9 steps.
3Adjusting the Slide Position [SLIDE]
Touch [ 3 ] to slide the monitor one step to the front.
Touch [ 2 ] to slide the monitor one step to the back.
This slide position can be adjusted in 3 steps.
3Turning the Automatic Open/Close
Function On/Off [AUTO OPEN-CLOSE]
Touch [ ON ] or [ OFF ] to switch the function on and
off.
: Switch the ACC ON/OFF to open/close
the monitor
: Use the OPEN/CLOSE button to
open/close the monitor
If the shift lever or other parts of the vehicle interfere
with the monitor when it opens, select [ OFF ].
3Switching to the Screen Control Screen
Touch [ SCREEN ] to switch to the screen control
screen.
3Ending the Angle Control Screen
Touch [ OK ] .
NOTE
NOTE
NOTE
OK
ANGLE CTRL
SCREEN
AUTO
OPEN - CLOSE
ANGLE
SL IDE
ON OFF
Angle Control Screen
BRT
TIN
COL
OK
SCREEN CTRL
ANGLE
BLK
CONT
DIM
ON
OFF
Screen Control Screen
■ O F F
■ O N
■ O F F
■ O N

Kenwood KVC-1000 Specifications

Monitor

screen size (diagonal)	6.5-inch
screen size (width x height)	142.6mm x 80.7mm
number of pixels	336, 960 (480H x 234V x RGB)

Speaker

audio output	1W
speaker dimensions	40mm x 20mm
antenna input	4ch Diversity System (75Q / Mini Plug 3.5¢)

General

operating voltage	14.4V (11V ~ 16V)
current consumption	2.0A (1.4A during normal operations)
operating temperature range	-10°C ~ +60°C

Weight and Dimensions

main unit size (width x height x depth)	180mm x 50mm x 182mm
installation size (width x height x depth)	178mm x 50mm x 165mm
main unit weight	1.8Kg
