COMBINATION SWITCH
The combination switch consists of
the head light, turn signal light, and
horn switches. Its function by its po-
sition is as follows:
tb3O419A
(1) Turn Signal Light Switch
(2) Head Light Switch
(3) Horn Switch
• OFF :
Head light and tail light “OFF”
• :
Head light “OFF” and tail light “ON”
• :
Low beam and tail light “ON”
tb3O420A
HEAD LIGHT SWITCH
Driving with high beam head
light disturbs an approach-
ing vehicle’s visibility for safe
driving. Use the high beam
head lights only if necessary.
WARNING
(1) Head Light Switch
(A) “OFF” (B) (C)
The head light switch can be operated
only while the key switch is turned to
the “ON” position. Turning the head
light switch clockwise one click will
tail lights while turning it one more
click will illuminate the low beam head
lights and tail lights.
