JUMP STARTING THE ENGINE
(1) Dead Battery (2) Jumper Cables
(3) Helper Battery
If the battery is discharged and the
engine cannot be started, it is possible
to start the engine by connecting the
discharged battery to a battery from
another tractor or other extra battery.
M46O503A
6. Start the engine of the tractor
with the charged battery.
7. Start the engine of the tractor
with the discharged battery.
8. Disconnect the black cable from
the negative battery terminals of
both of the tractors.
9. Disconnect the red cable.
10. Run the engine for at least 30
minutes to charge the discharged
battery.
11. If the battery is discharged again,
replace it or check the charging
system, such as the alternator.
1. Check that the voltage of the dis-
charged battery is same as the
voltage of the other tractor or ve-
hicle for jump start. (Specication
for this tractor: 12V)
2. Check the length of the jump cable
and position another tractor near
the tractor with the discharged bat-
tery. Then, put all the shift levers in
the neutral position, apply the park-
ing brake, and stop the engine.
3. Wear protective glasses and gloves
and open the hoods of both trac-
tors. Remove the battery terminal
cover as necessary.
4. Connect the alligator clips on both
ends of the red positive cable to the
positive terminals of both batteries.
5. Connect one clip of the black nega-
tive cable to the negative terminal
of the normal battery and the other
clip to the tractor body with the dis-
charged battery. Make sure to con-
nect the clip to a part of the frame
without paint.
