- 20 -
4. Instrument Panel and Controls
4.1 Switches
623O401A
Key Switch
Inserting the key and turning it one click to the right,
closes the electrical circuit and lights up the engine
oil pressure lamp (RED). Depress the clutch pedal to
disengage the clutch. Next, turning the key right acti-
vates the glow plug, proceeding to preheat the com-
bustion chamber. After the glow plug lamp has turned
off the engine has been preheated completely, turn the
key switch right and the cell starter will start to rotate
and the engine should start. Release the key switch
and it will return to the ON position.
NOTE :
• Because of the safety device, the engine will not be
started except when the clutch is disengaged
623O402A
