Governor System
58 19 690 01 Rev. --KohlerEngines.com
Governor Adjustments
A
A 9.5 mm ± 0.5 (0.37 in. ± 0.02)
NOTE: Do not tamper with governor setting. Overspeed
is hazardous and could cause personal injury.
Initial Adjustment Procedure
Make this adjustment whenever governor arm is
loosened or removed from cross shaft. Adjust as follows:
1. Make sure governor linkage is connected to
governor lever and throttle lever on throttle body.
2. Loosen nut holding governor lever to cross shaft.
3. Move governor lever toward throttle body as far as it
will go (wide open throttle) and hold in this position.
4. Insert a long thin rod or tool into hole on cross shaft
and rotate shaft counterclockwise (viewed from end)
as far as it will turn.
5. Adjust governor lever to maintain correct location
from end of governor cross shaft. Torque nut to
7.1 N·m (63 in. lb.).
