Reassembly
96
19 690 01 Rev
. --
KohlerEngines.com
Blower Housing/Starter Motor/Fuel Pump Components
A
B
C
F
E
D
H
J
M
N
K
I
G
L
O
A
ECU
B
Recti
fi
er-Regulator
C
Starter Motor
Assembly
D
Fuel Pump Module
E
Fuel Pump
Module Baf
fl
e
F
Oil Fill T
ube
G
W
asher
H
Spacer
I
Support Rings
J
Debris Screen
K
W
asher
L
Screw
M
Spacer
N
Fixed Guard
O
Blower Housing
95
97
