Disassembly/Inspection and Service
70 19 690 01 Rev. --KohlerEngines.com
WARNING
Before working on engine or equipment, disable engine as
follows: 1) Disconnect spark plug lead(s). 2) Disconnect
negative (–) battery cable from battery.
Accidental Starts can cause severe injury or
death.
Disconnect and ground spark plug lead(s)
before servicing.
External Engine Components
A
C
M
B
E
D
H
K
K
L
L
C
I
N
F
G
J
O
P
O
Q
R
A Oil Filter B Dipstick C Oil Drain Plug D
High Pressure
Fuel Line
E Pulse Line F
Low Pressure
Fuel Line
G Fuel Filter H Breather Hose
I
Throttle Body
Bracket
J Manifold Assembly K Spark Plug Lead L Manifold Screw
M Oil Cooler N
Fuse Holder
Bracket
O J-Clip P Clamp
Q
Fuel Pump
Module (FPM)
R Fuel Pump
To Next Page
