Section 7 Decision-Makerr 6000 Controller TP-6356 4/12
7.6.3 User-Defined Settings
Use the table below to record user-defined settings
during the generator set controller setup and calibration.
The controller default settings and ranges provide
guidelines. The table contains all faults with ranges and
time delays including items that do not have
adjustments. Not adjustable user-defined settings
result when the controller logic does not allow changes
or the values are engine limited.
Note: Inhibit time delay is the time delay period after
crank disconnect.
Note: The engine ECM may limit the crank cycle even if
the controller is set to a longer time period.
Note: Entering 99.99, where applicable, designates
infinite delay and no shutdown. This value
effectively disables a fault shutdown.
User-Defined Settings
Status Event
or Fault
Refer
to
Menu
Digital Display
Relay
Driver
Output
(RDO)
Range Setting
Default
Selection
Inhibit
Time
Delay
(sec.)
Time
Delay
(sec.)
User-Defined
Settings
Access Code
(password)
14 User-Selectable 0(zero)
AC Sensing Loss 10 AC SENSING
LOSS
Not adjustable
Alternator Protection 10 ALTRNTR
PROTECT
SDWN
RDO-19 Not adjustable
Alternator Protection
kW Overload
10 ALTRNTR
PROTECT
SDWN KW
Fixed 102% Std.
112% Prime
60 Not adjustable
Analog Aux. Input 0 9 LOCAL BATT
VDC
Fixed Not adjustable
Analog Aux. Inputs
A01--A07
9 USER-DEFINED
A01--A07
Default Values with
Warning Enabled:
HI warning 90%
LO warning 10%
HI shutdown 100%
LO shutdown 1%
30 sec.
inhibit,
5 sec. delay
0--60 0--60
Battery Charger Fault
D01 [
9, 10 BATTERY
CHARGER
FAULT D01
RDO-12
(lead 61)
Fixed 0 sec.
inhibit,
0 sec. delay
Not adjustable
Battle Switch
(Fault Shutdown
Override Switch)
9 BATTLE
SWITCH
Fixed 0 0 Not adjustable
Breaker Close
Control
10 CLOSE
BREAKER
RDO-30 Not adjustable
Breaker Closed D05 9, 10,
17
Fixed 0 sec.
inhibit,
0 sec. delay
Not adjustable
Breaker Trip Control 10 BREAKER
TRIP
RDO-31 Not adjustable
Circuit Breaker Close
Attempts Fault
10, 17 CB CLOSE
ATTS FAULT
1--100 Attempts
Circuit Breaker
Common Fault
10 CB COMMON
FAULT
RDO-28 Fixed 0 0 Not adjustable
Circuit Breaker
Current Fault
10, 17 CB CURRENT
FAULT
1%--50% of
rated current
0--60
Circuit Breaker Open
Fault
10, 17 CB OPEN
FAULT
0.3--
30 ]
Circuit Breaker Trip
to Shutdown Time
Delay
10, 15 CB TRIP TO
SD TD
See Menu 15, Time
delay circuit breaker
trip to shutdown
5min. 0 0--60
min.
or
infinite
Common Protective
Relay Warning
10 COMMON PR
OUTPUT
RDO-29 Not adjustable
Critical Overvoltage
Shutdown
10 CRITICAL
OVERVOLTAGE
Fixed 275 volts
(L1--L2)
0 0 Not adjustable
* DD/MTU engine with MDEC/ADEC
[ NFPA applications
] 3x (times) energize time shown in Menu 17
