TP-6356 4/12 67Section 4 Decision-Makerr 340 Controller
4.2.4 User-Defined Settings
Use the table below to record user-defined settings
during the generator set controller setup and calibration.
The controller default settings and ranges provide
guidelines. The table contains all faults with ranges and
time delays including items that do not have
adjustments.
Status or Fault
Refer
to
Menu
Digital Display
Relay
Driver
Output
(RDO)
Range Setting
Default
Selection
Inhibit
Time
Delay*
(sec.)
Time
Delay
(sec.)
User-Defined
Settings
Access Code
(Password)
11 0(zero)
Cyclic Cranking 4
1--6 crank cycles
1--60 sec. crank
1--60 sec. pause
3
15 sec.
15 sec.
Coolant
Temperature Signal
Loss
5
No Temp Gauge
Signal
User
Defined
30
Customer Auxiliary
1--4 Shutdown or
Warning
4, 5 Auxiliary 1--4
User
Defined
30 sec.
inhibit,
5 sec. delay
0--60 0--60 Not adjustable
Emergency Power
System Supplying
Load
5
EPS Supplying
Load
RDO—8
5% of line
current
High Battery Voltage 5, 6
High Battery
Voltage
RDO—10
14.5--16.5 (12V)
29--33 (24V)
16 (12V)
32 (24V)
10
High Coolant
Temperature
Shutdown
5
High Coolant
Temperature
Std. 30 5 Not adjustable
High Coolant
Temperature
Warning
5
High Coolant
Temperature
Warning
Std. 30 Not adjustable
High Oil
Temperature
Shutdown
5
High Oil
Temperature
User
Defined
30 5 Not adjustable
kW Overload
(Load Shed)
Load Shed 5
Load Shed
KW Overload
User
Defined
100% of kW
Rating
5
Load Shed
Underfrequency
User
Defined
59, (60 Hz)
49, (50 Hz)
5
Low AC Output 5 Low AC Output
User
Defined
10
Low Battery Voltage 5, 6
Low Battery
Voltage
Std.
10--12.5 (12V)
20--25 (24V)
12 (12V)
24 (24V)
10
Low Coolant Level
Shutdown
5
Low Coolant
Level
RDO—7 30 5 Not adjustable
Low Oil Pressure
Shutdown
5
Low Oil
Pressure
Std. 30 5 Not adjustable
Low Oil Pressure
Warning
5
Low Oil
Pressure
Warning
Std. 30 Not adjustable
Overcrank
Shutdown
5 Overcrank Std.
Overcurrent 5 Overcurrent
User
Defined
110% 10
Overfrequency
Shutdown
5, 6 Overfrequency
User
Defined
102%--140%
140% Std.
103% FAA
10
Overspeed
Shutdown
5, 6 Overspeed Std.
65--70 (60 Hz)
55--70 (50 Hz)
70 (60 Hz)
70 (50 Hz)
0.25
* Inhibited time delay is the time delay period after crank disconnect.
