Method for checking oil level when the engine is stopped
• As a reference, check the
marks (C) and (D) on dipstick
(G) marked with “COLD STOP” side.
• Stop the engine, and wait for 2 hours or longer before
checking.
• For the final oil level check, use “HOT IDLE” side of dip-
stick (G) according to the preceding steps 1 to 8, after
completing the warm-up operation of the transfer.
METHOD FOR CLEANING ENGINE DAMPER BREATHER
WARNING
Immediately after the engine is stopped, parts and oil are still very hot. Wait for the temperature to go
down, and then start the work.
1.
Remove the bolts (1) (3 pieces) and remove the cover (2).
2.
Remove the bolts (3) (4 pieces) and remove the cover (4).
3.
After removing dirt and dusts around the breather (5), re-
move
the breather (5) and
immerse it in detergent liquid to
clean.
While the breather is removed, use care to prevent entry of
dusts through the mounting location of the breather.
MAINTENANCE MAINTENANCE PROCEDURE
4-27
