METHOD FOR CHECKING AND INFLATING TIRE
WARNING
• When
pumping up the tires, check that no other person is standing near the tire, and install an air
chuck with a clip that can be secured to the air valve.
•
T
o
prevent
the tire inflation pressure from becoming too high, measure the pressure from time to
time with an air gauge while pumping up the tire.
• When it is inflated, the rim parts may fly out, if they are not fitted properly.
Put a fence around the tire for protection. The worker must not stand in front of the rim but must
stand on the tread side during work.
• Abnormal drop of inflation pressure and abnormal fitting of the rim indicate a trouble in the tire or
rim. In this case, be sure to ask a tire repair shop for repair.
• Be sure to observe the specified inflation pressure.
• Do not adjust the tire inflation pressure immediately after traveling at high speed or operating under
heavy load.
Check the tire inflation pressure before starting work while the tires are cold.
When inflating a tire, use an air chuck which can be fixed to the air valve of the tire as shown in the figure.
Do not work in front
of the rim but work on the tread side of the
tire.
1.
Measure the inflation pressure with a tire inflation pressure gauge.
2.
Adjust the inflation pressure properly.
The proper inflation pressure is shown below.
Tire size Standard inflation pressure
Radial 20.5R25☆ (L3 Rock)
Front wheel: 425
kPa {4.25 kg/cm
2
}
Rear wheel: 400 kPa {4.0 kg/cm
2
}
Bias 20.5-25-12PR
Front wheel: 330 kPa {3.3 kg/cm
2
}
Rear wheel: 280 kPa {2.8 kg/cm
2
}
NOTICE
Appropriate inflation pressure varies depending
on the given type of work. For details, see “HAN-
DLE TIRE (3-211)”.
METHOD FOR CLEANING AND REPLACING FUEL TANK BREATHER ELEMENT
CAUTION
If you perform inspection or cleaning while the engine is running, dirt enters the fuel tank and damages
the engine.
Be sure to stop the engine before performing these works.
MAINTENANCE PROCEDURE MAINTENANCE
4-42
