METHOD FOR ADJUSTING JOYSTICK CONSOLE
WARNING
• Perform adjustment after placing the machine in a level and safe place.
•
Adjust it before starting operation or when operators change shift.
•
Adjust
the
operator's
seat so that you can depress the brake pedal fully when you are sitting with
your back contacted to backrest of operator's seat, and adjust the console.
• Tighten the knob completely after performing fore-and aft adjustment of joystick console.
• Lower the joystick console and loose up-down adjustment
knob (1) to adjust the height of it.
• Adjust the angle of the armrest by loosing lever (2).
HANDLE JOYSTICK STEERING SYSTEM ATTACHMENTS AND OPTIONS
