3 KONICA machine main parts picture
Main parts instruction
front
1、left-up lid 2、hinge 3、left-front-up lid
4 、 left-front-down
lid
5、left-up box 6、left-down box 7、heater front lid 8、fan lid
9、lift stick 10 、 left ink tank
shelf
11、left main leg 12、adjust leg
13、roller 14 、 media-up left
baffle
15media-up left
bracket
16、media-up roller
17、down beam 18 、 rubber feed
roller
19、feed roller 20、media pressure
21、air draft 22 、 pinch roll
system
23、fasten shaft 24liner slider
25、raster 26、carriage 27 、 fasten shaft
bracket
28、junction plate
29、media-up motor
30、right main leg 31、media-up right
baffle
32、fasten handle
33、right ink tank
shelf
34、right feed baffle
36、right-down box
side lid
37、right up box 38 、 39 、 right-front-up 40、middle-front lid
