6 CONTROLS 17
6.13 Foot brake lever
401956-10
Foot brake lever
is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.14 Plug-in stand (All SX models)
402001-10
The holder for plug-in stand
is on the left side of the wheel spindle.
The plug-in stand is used to park the motorcycle.
Info
Remove the plug-in stand before riding.
6.15 Side stand (All XC models)
401943-10
Side stand
is located on the left side of the vehicle.
401944-10
The side stand is used for parking the motorcycle.
Info
When you are riding, side stand
must be folded up and secured with rubber
band
.
6.16 Service hour counter
K00484-10
The service hour counter
is fitted in front of the handlebar.
It shows the total number of service hours of the engine.
The service hour counter begins counting when the engine is started and stops when
the engine is switched off.
Info
It is not possible to delete or adjust anything on the service hour counter.
