15 WHEELS, TIRES 140
S00364-10
–
Loosen screws
4
and
5
.
–
Unscrew screw
4
about six turns and press your hand on the screw to push the wheel
spindle out of the axle clamp. Remove screw
4
.
Warning
Danger of accidents Reduced braking efficiency due to damaged brake discs.
– Always lay down the wheel in such a way that the brake discs are not dam-
aged.
– Holding the front wheel, withdraw the wheel spindle. Take the front wheel out of the
fork.
Info
Do not pull the hand brake lever when the front wheel is removed.
S00316-10
–
Remove spacers
6
.
