KTM 2014 1190 Adventure User Manual

7 COMBINATION INSTRUMENT 55
7.9.4 "General Info"
401824-01
– Press the UP oder DOWN button until the "General Info" menu appears on the matrix dis-
play.
"Air Temp" indicates the ambient air temperature.
"Date" indicates the date.
"ODO" indicates the total distance covered.
"Battery" indicates the battery voltage.
"Oil Temp" indicates the engine oil temperature.
7.9.5 "TPMS" (optional)
401845-01
– Press the UP or DOWN button until the "TPMS" menu appears on the matrix display.
Guideline
Tire air pressure, solo/with passenger/full payload
Front: with cold tires 2.4 bar (35 psi)
Rear: with cold tires 2.9 bar (42 psi)
The "TPMS" menu displays the tire pressure of the front and rear tires.
"Front" indicates the tire air pressure at the front.
"Rear" indicates the tire air pressure at the rear.

KTM 2014 1190 Adventure Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	12.5:1
Torque	125 Nm @ 7500 rpm
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP USD Ø 48 mm
Front Tire	120/70 ZR 19
Rear Tire	170/60 ZR 17
Dry Weight	217 kg
Fuel Capacity	23 liters
Power	150 hp (110 kW) @ 9500 rpm
Clutch	PASC slipper clutch, hydraulically operated
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9ME Combined ABS
Seat Height	860 mm
