23 TECHNICAL DATA 209
Spring rate
Medium (standard) 160 N/mm (914 lb/in)
Spring length 205 mm (8.07 in)
Static sag 25 mm (0.98 in)
Riding sag 55 mm (2.17 in)
Fitted length 403 mm (15.87 in)
Shock absorber oil ( p. 215) SAE 2.5
23.9 Chassis tightening torques
Screw, combination switch, left M4 2 Nm (1.5 lbf ft)
Screw, side stand switch M4 2 Nm (1.5 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, brake line holder on swingarm M5 5 Nm (3.7 lbf ft)
Screw, cable channel M5 5 Nm (3.7 lbf ft)
Screw, cable guide, wheel speed sensor,
rear
M5 3 Nm (2.2 lbf ft)
Screw, chain sliding guard M5 5 Nm (3.7 lbf ft)
Screw, combination switch, right M5 3.5 Nm (2.58 lbf ft)
Screw, cover part M5x12 3.5 Nm (2.58 lbf ft)
Screw, filler cap M5 3 Nm (2.2 lbf ft)
Screw, foot brake lever stub M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, fuel level indicator M5 3 Nm (2.2 lbf ft)
Screw, heat guard on main silencer M5 4 Nm (3 lbf ft)
Screw, wind shield M5 3.5 Nm (2.58 lbf ft)
