KTM 2014 1190 Adventure User Manual

7 COMBINATION INSTRUMENT 50
7.5 Indicator lamps
401813-01
Possible states
The high beam indicator lamp lights up blue – The high beam is switched
on.
The immobilizer indicator lamp lights up/flashes red – Status or error mes-
sage for immobilizer/alarm system.
The oil pressure warning lamp lights up red – Engine oil pressure is too
low.
The general warning lamp lights up yellow – An operating safety (warning)
message was detected. This is also shown on the matrix display.
The left turn signal lamp flashes green simultaneously with the turn signal
– The left turn signal is switched on.
The idle indicator lamp lights up green – The transmission is shifted to
idle.
The right turn signal lamp flashes green simultaneously with the turn signal
– The right turn signal is switched on.
The engine warning lamp lights up/flashes yellow – The engine control unit
has detected a fault.
The ABS lamp lights up/flashes yellow – ABS is not active. The ABS lamp
also lights up when a fault is detected.
The TC lamp lights up/flashes yellow – Traction control is not enabled or is
currently intervening. The TC lamp also lights up when a fault is detected.

KTM 2014 1190 Adventure Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	12.5:1
Torque	125 Nm @ 7500 rpm
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP USD Ø 48 mm
Front Tire	120/70 ZR 19
Rear Tire	170/60 ZR 17
Dry Weight	217 kg
Fuel Capacity	23 liters
Power	150 hp (110 kW) @ 9500 rpm
Clutch	PASC slipper clutch, hydraulically operated
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9ME Combined ABS
Seat Height	860 mm
