KTM 2014 1190 Adventure User Manual

15 WHEELS, TIRES 146
S00285-10
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
–
Change the wheel bearing. x
–
Clean and grease shaft seal ring
1
and contact surface
A
of the spacer.
Long-life grease ( p. 218)
– Clean and grease the thread of the wheel spindle and nut.
Long-life grease ( p. 218)
– Mount the rubber dampers and rear sprocket carrier in the rear wheel.
– Place the rear wheel in the swingarm and bring the brake disc on the brake caliper into
contact.
S00287-10
–
Mount wheel spindle
2
but do not push it in all the way.
– Push the rear wheel as far forward as possible and place the chain on the rear sprocket.

KTM 2014 1190 Adventure Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	12.5:1
Torque	125 Nm @ 7500 rpm
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP USD Ø 48 mm
Front Tire	120/70 ZR 19
Rear Tire	170/60 ZR 17
Dry Weight	217 kg
Fuel Capacity	23 liters
Power	150 hp (110 kW) @ 9500 rpm
Clutch	PASC slipper clutch, hydraulically operated
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9ME Combined ABS
Seat Height	860 mm
