17 COOLING SYSTEM 181
602647-10
Main work
–
Remove cover
1
of the compensating tank.
602648-01
– Add coolant until the coolant reaches the specified level.
Guideline
The coolant level must be between MIN and MAX.
Alternative 1
Coolant ( p. 213)
Alternative 2
Coolant (mixed ready to use) ( p. 213)
– Mount the cover of the compensating tank.
Finishing work
– Install the front side cover. ( p. 117)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 2014 1190 Adventure and is the answer not in the manual?

KTM 2014 1190 Adventure Specifications

General IconGeneral
Engine Type2-cylinder, 4-stroke, V 75°
Displacement1195 cc
Bore x Stroke105 mm x 69 mm
Compression Ratio12.5:1
Torque125 Nm @ 7500 rpm
Fuel SystemElectronic Fuel Injection
Transmission6-speed
FrameChromium-Molybdenum steel trellis frame, powder coated
Front SuspensionWP USD Ø 48 mm
Front Tire120/70 ZR 19
Rear Tire170/60 ZR 17
Dry Weight217 kg
Fuel Capacity23 liters
Power150 hp (110 kW) @ 9500 rpm
ClutchPASC slipper clutch, hydraulically operated
Front Brake2 x Brembo 320 mm discs, 4-piston radial calipers
Rear BrakeBrembo 267 mm disc, 2-piston caliper
ABSBosch 9ME Combined ABS
Seat Height860 mm
