KTM 2014 1190 Adventure User Manual

23 TECHNICAL DATA 206
Front Double disc brake with radially mounted four-pot brake calipers,
floating brake discs
Rear Single disc brake with dual-piston brake caliper, floating brake
disc
Brake discs - diameter
Front 320 mm (12.6 in)
Rear 267 mm (10.51 in)
Brake discs - wear limit
Front 4 mm (0.16 in)
Rear 4.5 mm (0.177 in)
Tire air pressure, solo/with passenger/full payload
Front: with cold tires 2.4 bar (35 psi)
Rear: with cold tires 2.9 bar (42 psi)
Secondary drive ratio 17:42
Chain 5/8 x 5/16” (525) X‑ring
Steering head angle 64°
Wheelbase 1,560 mm (61.42 in)
Seat height, unloaded 860/875 mm (860/875 in)
Ground clearance, unloaded 220 mm (8.66 in)
Weight without fuel, approx. 212 kg (467 lb.)
Maximum permissible front axle load 159 kg (351 lb.)
Maximum permissible rear axle load 281 kg (619 lb.)
Maximum permissible total weight 440 kg (970 lb.)

KTM 2014 1190 Adventure Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	12.5:1
Torque	125 Nm @ 7500 rpm
Fuel System	Electronic Fuel Injection
Transmission	6-speed
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP USD Ø 48 mm
Front Tire	120/70 ZR 19
Rear Tire	170/60 ZR 17
Dry Weight	217 kg
Fuel Capacity	23 liters
Power	150 hp (110 kW) @ 9500 rpm
Clutch	PASC slipper clutch, hydraulically operated
Front Brake	2 x Brembo 320 mm discs, 4-piston radial calipers
Rear Brake	Brembo 267 mm disc, 2-piston caliper
ABS	Bosch 9ME Combined ABS
Seat Height	860 mm
