6 CONTROLS 17
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
– Fuel must not come into contact with the skin, eyes, or clothing. Do not breathe in the fuel vapors. If contact occurs with
the eyes, rinse with water immediately and contact a physician. Immediately clean contaminated areas on the skin with
soap and water. If fuel is swallowed, contact a physician immediately. Change clothing that has been contaminated with
fuel. Store fuel properly in a suitable canister and keep away from children.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
– Do not allow fuel to get into the ground water, the ground, or the sewage system.
K00109-11
–
Press release button
, turn filler cap counterclockwise and lift it upwards and
remove.
6.16 Closing filler cap
K00109-10
–
Replace the filler cap and turn clockwise until the release button
locks in
place.
Info
Route the fuel tank breather hose
without kinking.
6.17 Idle speed adjusting screw
L02462-10
Idle speed adjusting screw
is located at the top left of the throttle valve body.
The idle speed adjusting screw has two functions.
Turning it controls the idle speed.
Pulling it out all the way raises the idle speed during a cold start.
Possible states
• RPM increase activated – Idle speed adjusting screw is pulled out all the way.
• RPM increase deactivated – Idle speed adjusting screw is pushed in all the way.
