CONTROLS 13
5.12Kick starter (XC‑F)
100910-10
The kick starter 1 is fitted on the right side of the engine.
The upper part of the kick starter can be folded in.
Info
Before riding, fold the upper part of the kick starter toward the engine.
5.13Foot brake lever
100911-10
Foot brake lever 1 is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
5.14Plug-in stand (All SX‑F models)
100950-10
The holder for the plug-in stand 1 is the left side of the wheel spindle.
The plug-in stand is used to park the motorcycle.
Info
Remove the plug-in stand before starting on a trip.
5.15Side stand (XC‑F)
101084-10
The side stand 1 is on the left side of the vehicle.
101085-10
The side stand is used to park the motorcycle.
Info
When you are riding, side stand 1 must be folded up and secured with rubber
band 2.
