TUNING THE CHASSIS 31
Info
Position the left and right handlebar supports evenly.
– Position the handlebar.
Info
Make sure cables and wiring are positioned correctly.
– Position the handlebar clamp. Mount and evenly tighten the four screws 1.
Guideline
Screw, handlebar clamp M8 20 Nm
(14.8 lbf ft)
9.16Activating the Factory Start (SX‑F ROCZEN REPLICA)
Info
In cold weather, the lock button may freeze up, preventing it from being released during compression.
101078-10
– Check lock button 1 to ensure it can move easily.
– Bend over the handlebars while sitting on the motorcycle. Grip the rim and com-
press the fork. Press lock button 1 and decompress slowly until the lock button
engages in lock ring 2.
When the fork compresses for the first time, the lock button is released auto-
matically.
