TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 95

Spoke nipple, front wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) –

Spoke nipple, rear wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) –

Screw, battery terminal M5 2.5 Nm (1.84 lbf ft) –

Screw, intake air temperature sensor M5 2 Nm (1.5 lbf ft) –

Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, throttle grip M6 3 Nm (2.2 lbf ft) –

Fuel connection on fuel tank (XC‑F) M8 10 Nm (7.4 lbf ft) –

Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)

Loctite

2701

Nut, rim lock M8 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, engine brace M8 33 Nm (24.3 lbf ft) –

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, side stand attachment (XC‑F) M8 45 Nm (33.2 lbf ft)

Loctite

2701

Screw, subframe M8 35 Nm (25.8 lbf ft)

Loctite

2701

Screw, top steering stem M8 17 Nm (12.5 lbf ft)

Loctite

243™

Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –

Engine carrying screw M10 60 Nm (44.3 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 60 Nm (44.3 lbf ft)

Loctite

2701

Screw, handlebar support M10 40 Nm (29.5 lbf ft)

Loctite

243™

Screw, top shock absorber M10 60 Nm (44.3 lbf ft)

Loctite

2701

Nut, fuel pump (XC‑F) M12 15 Nm (11.1 lbf ft) –

Nut, seat fixing M12x1 20 Nm (14.8 lbf ft) –

Nut, frame to linkage lever M14x1.5 80 Nm (59 lbf ft)

Loctite

2701

Nut, linkage lever on swingarm M14x1.5 80 Nm (59 lbf ft) –

Nut, linkage lever to angle lever M14x1.5 80 Nm (59 lbf ft) –

Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –

Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft) –

Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –

Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft)

Loctite

243™

Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft) –
