KTM 450 EXC-F 2022 User Manual

1 MEANS OF REPRESENTATION
2
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Indicates a voltage measurement.
Indicates a current measurement.
Indicates a resistance measurement.
Indicates the end of an activity including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name
®
Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

KTM 450 EXC-F 2022 Specifications

General

Displacement	449.9 cc
Bore x Stroke	95 mm x 63.4 mm
Compression Ratio	12.75:1
Fuel System	Electronic Fuel Injection
Throttle Body	42 mm
Transmission	6-speed
Final Drive	Chain
Front Brake	260 mm disc
Rear Brake	220 mm disc
Starter	Electric Starter
Engine Type	Single Cylinder, 4-Stroke
Front Suspension	WP XPLOR 48
Rear Suspension	WP XPLOR shock absorber
Seat Height	960 mm
Frame	Central tube frame made of chrome molybdenum steel tubing

Summary

Setup

Transport Mode

Unpacking and Setting Up the Vehicle

Details the initial steps for unpacking the motorcycle and preparing it for setup.

Work

Raising the Motorcycle with the Lift Stand

Removing the Motorcycle from the Lift Stand

Removing the Headlight Mask with the Headlight

Installing the Headlight Mask with the Headlight

Checking the Headlight Setting

Provides steps to check and verify the correct headlight beam setting.

Adjusting the Headlight Range

Explains how to adjust the headlight's range for optimal visibility and safety.

Installing the Shock Absorber

Guides through the process of mounting and securing the motorcycle's shock absorber.

Installing the Fork Legs

Details the steps for installing the front fork legs, including tightening specifications.

Installing the Front Wheel

Outlines the procedure for installing the front wheel, including safety warnings.

Installing Front Fender

Disconnecting the Negative Cable of the 12-V Battery

Guides on how to safely disconnect the negative terminal of the 12-V battery.

Connecting the Negative Cable of the 12-V Battery

Removing the 12-V Battery

Installing the 12-V Battery

Charging the 12-V Battery

Explains the correct procedures and warnings for charging the 12-V battery.

Installing the Engine Guard (XCF-W, EXC-F Six Days)

Refueling

Provides essential information and safety precautions for refueling the motorcycle.

Setting the Combination Instrument

Setting the Clock

Technical Data

Chassis Tightening Torques

Lists specific tightening torques for various chassis screws and bolts.
