6 CONTROLS
18
6.8 Turn signal switch (All EU models)
S01304-10
The turn signal switch
1
is fitted on the left side of the handle-
bar.
Possible states
Turn signal off – Turn signal switch is in the central
position.
Turn signal, left, on – The turn signal switch is turned
to the left.
Turn signal, right, on – The turn signal switch is
turned to the right.
6.9 Emergency OFF switch
V01749-10
(All EU models)
The emergency OFF switch
1
is fitted on the right side of the
handlebar.
Possible states
Ignition off – In this position, the ignition circuit
is interrupted, a running engine stops, and a
non-running engine will not start.
Ignition on – In this position, the ignition circuit is
closed and the engine can be started.
6.10 Start button
V01749-11
(All EU models)
Start button
1
is fitted on the right side of the handlebar.
V01750-10
(XCF‑W)
Start button
1
is fitted on the right side of the handlebar.
Possible states
• The start button is in the basic position
• The start button is pressed – The starter motor is actuated
in this position.
