20 TECHNICAL DATA
120
Grease capacity, left cartridge 5 g (0.18 oz) Special grease (00062010053)
( p. 126)
20.8 Shock absorber
Shock absorber article number 12.18.7U.04
Shock absorber WP SuspensionXACT 5746
High-speed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Low-speed compression damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Rebound damping
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Spring preload 11 mm (0.43 in)
Spring rate
Weight of rider: < 45 kg (< 99 lb.) 35 N/mm (200 lb/in)
Weight of rider: 45 … 55 kg (99 … 121 lb.) 40 N/mm (228 lb/in)
Weight of rider: > 55 kg (> 121 lb.) 45 N/mm (257 lb/in)
Spring length 215 mm (8.46 in)
Gas pressure 10 bar (145 psi)
Static sag 30 mm (1.18 in)
Riding sag 120 mm (4.72 in)
Fitted length 397 mm (15.63 in)
Shock absorber fluid ( p. 124) SAE 2.5
20.9 Chassis tightening torques
Screw, stop button M3 0.4 Nm (0.3 lbf ft)
Screw, carburetor cover M4 2 Nm (1.5 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple M4.5 5 Nm (3.7 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, main silencer M5 7 Nm (5.2 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Nut, push rod, foot brake lever M6 6 Nm (4.4 lbf ft)
Pin, front brake M6 8 Nm (5.9 lbf ft)
Pin, rear brake M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
