WHEELS, TIRES 112
12.2Installing the front wheel x
Warning
Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.
B00634-10
– Check the wheel bearing for damage and wear.
» If the wheel bearing is broken or worn:
–
Replace the wheel bearing. x
– Clean, grease, and mount the left and right spacers and the shaft seal rings.
Long-life grease ( p. 210)
– Clean screw and wheel spindle .
– Lift the front wheel into the fork, position it, and insert the wheel spindle.
The arrow on the spoke indicates the direction of travel.
– Mount and tighten screw .
Guideline
Bolt, front axle M25x1.5 45 Nm
(33.2 lbf ft)
