CONTROLS 45
5.28Combination instrument - coolant temperature indicator
700124-01
The temperature display consists of 12 bars. The more bars that light up, the hotter the
coolant. When the upper bar lights up, all bars in the display begin to flash and the temper-
ature warning lamp lights up.
Possible states
• Engine cold – Up to five bars light up.
• The engine is warm – Six to eleven bars light up.
• Engine hot – All twelve bars flash.
5.29Hazard warning flasher switch/hazard warning flasher
B00658-10
The hazard warning flasher switch is fitted next to the combination instrument on the
left.
The hazard warning flasher is used to indicate emergency situations.
Info
The hazard warning flasher can be activated or deactivated while the ignition is
switched on or up to 30 seconds after the ignition is switched off.
Do not keep the hazard warning flashers activated longer than necessary as they
deplete the batteries.
Possible states
Hazard warning flasher off
Hazard warning flasher on – All four turn signals, the hazard warning
flasher switch, and the green turn signal indicator light in the combination
instrument flash.
