(A) Tie-down point (Do not tow
here.)
1.
Attach towing hardware using both rear tow points
and to the towing machine as shown in the
following figure.
(1) Chain or strap (A) Rear tow and tie-down
points
2. Sit on the operator's seated in the towed machine
with the seat belt connected during the recovery
process, and assist when towed using the machine
movement in the direction of towing. Keep the
parking brake released while towing.
3. Tow slowly at a walking pace with recovery machine
and towed machine, avoid abrupt loads while
towing.
TOWING AN INOPERABLE
MACHINE
WARNING
To avoid personal injury or death:
• Do not tow the machine without disengaging
the hydraulic-drive-system, otherwise damage
to the hydraulic drive or tire system will occur.
• Follow proper procedures to disengage
hydraulic-drive-system before towing the
machine. After disengaging the hydraulic-drive-
system, tow the machine following the steps.
Contact your KUBOTA dealer for more
information.
• Tow only from both rear tie-downs as shown in
the figure.
• Towing is only allowed for a short distance at
walking speed.
• Use a tow chain or rope and hardware that is
rated at least 1.5 times the machine weight.
See the Technical data section in this operator's
manual to find machine weight.
(See SPECIFICATION TABLE on page 25)
1. Attach the towing hardware using both rear tow
points and to the towing machine as shown in the
following figure.
(1) Chain or strap (A) Rear tow and tie-down
points
2. Tow slowly at a walking pace with the recovery
machine and the towed machine, avoid abrupt
loads while towing the machine.
TOWING AN INOPERABLE MACHINE TRANSPORTING
