Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA
1-1
1 Specifications
1-1 Specifications
(1) Common function
Item Description
40 ppm model 35 ppm model
P2040dw P2040dn P2235dw P2235dn
Type Desktop
Printing Method Electrophotography by semiconductor laser
Paper Weight Cassette
60 to 163 g/m
2
Multi Purpose
Tray
60 to 220 g/m², 209g/m² (Hagaki)
Paper Type Cassette Plain, Rough, Recycled, Preprinted, Bond, Color, Prepunched,
Letterhead, Thick, High Quality, Custom 1 to 8 (Duplex:
Same as Simplex)
Multi Purpose
Tray
Plain, Transparency (OHP film), Rough, Vellum, Labels, Recy-
cled, Preprinted, Cardstock, Coated, Color, Prepunched, Let-
terhead, Envelope,
Thick, High Quality, Custom 1 to 8
Paper Size Cassette A4, A5-R, A5, A6, B5, Letter, Legal, Folio, 216 × 340 mm,
Statement, Executive, Oficio II, 16K, B5(ISO),
Custom (105 x 148 to 216 x 356 mm)
Multi Purpose
Tray
A4, A5-R, A5, A6, B5, B6, Letter, Legal, Folio, 216 × 340 mm,
Statement-R,Executive, Oficio II, 16K, B5(ISO),
Envelope #10, Envelope #9, Envelope #6 3/4,
Envelope Monarch, Envelope DL, Envelope C5, Hagaki (Card-
stock), Oufukuhagaki (Return postcard), youkei 4, youkei 2,
Custom (70 x 148 to 216 x 356 mm)
Printable Area Print margin for top, bottom and both sides is 4.2 mm.
Warm-up Time
(23°C/ 73.4°F,
60%)
Power on 15 seconds or less
Sleep 10 seconds or less
Paper Capac-
ity
Cassette
300 Sheets (64 g/m2)
*1
250 Sheets (80 g/m2)
*1
Multi Purpose
Tray
120 sheets (A4/Letter or smaller) (64 g/m2)
100 sheets (A4/Letter or smaller) (80 g/m2)
Output Tray
Capacity
Inner tray 250 sheets (80 g/m²)
Image Write System Semiconductor laser and electrophotography (twin beams)
Photoconductor OPC drum (diameter 30 mm)
Charging system Positive charge scorotron system
Developer system Magnetic mono-component developing system
Toner: magnetic toner
Toner feed system: leveled toner feed
Transfer system Transfer roller method

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
