Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-97
Content of Print Errors
(1) The paper loading message appears
(20) Print out is not available from the printer driver
setting factor (2)
A PC does not recognize the main unit.
(21) Print out is not available from the printer driver
setting factor (3)
PC operation does not stabilize.
(22) Print out is not available from the printer driver
setting factor (4)
Printer port supporting the network print is not
selected or not set up properly.
(23) Print out is not available from the printer driver
setting factor (5)
The incorrect printer driver was selected.
(24) Print out is not available from the printer driver
setting factor (6)
Installed printer driver shows "Deleting" and it
remains when reinstalling it
(25) A part of the image is missing The image data processing with a certain appli-
cation (Excel, PDF, etc.) is faulty.
(26) "Paper Mismatch Error" appears The paper size is not detected properly.
Step Check description Assumed cause Measures Reference
1 Changing paper Paper size is unmatched
between the PC side out-
put size and cassette side
paper size.
Load the paper in the paper
source of the size which is
set at [Output Size] in [Printer
Setting] > [Basis Setting] at
the PC.
2 Changing the settings Paper size displayed on
the operation panel
unmatched the size sent in
the cassette.
Check if the paper size dis-
played on the operation panel
matches the size of paper
loaded in the paper source. If
not, change the paper size in
the system menu.
3 Re-setting the guide The guide is not aligned to
the paper size.
Align the paper width guide,
paper guide (MP tray) or PF
paper width guide (paper
feeder) to the paper size and
re-load paper.
4 Checking the actuator and
the spring
The paper sensor does not
operate properly.
The actuator or spring for the
paper sensor, MP paper sen-
sor or PF paper sensor is
deformed or does not operate
properly, replace it.
5 Checking the situation The print data generated
by a certain application
(Word, etc.) is faulty.
Check if the print data not
generated by a certain appli-
cation (Word, etc.) is output
properly. And then, change
the application setting if nec-
essary.
No. Contents Condition

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
