Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-68
7-3Self diagnostic
(1) Self diagnostic function
This machine is equipped with a self-diagnostic function. When a problem is detected, the machine stops
operating and displays an error message on the operation panel. An error message consists of a message
prompting a contact to service personnel and a four-digit error code indicating the type of error.
(2) Self diagnostic codes
If the parts of the failure cause is not supplied, replace the unit that includes it.
Before attempting to check the fuser unit and the low voltage power supply PWB, be sure to turn the power
switch off and unplug the machine from power. (Allow at least 5 s before starting to conduct service until the
capacitors on the circuit boards have been completely discharged.)
(2-1) Error codes list
Error code Contents
C0100 Backup memory device error
C0120 MAC address data error
C0130 Backup memory reading/writing error
C0140 Backup memory data error
C0150 Engine EEPROM data error
C0160 Engine EEPROM data error
C0170 Charger count error
C0180 Machine serial number mismatch
C0190 Backup memory device error (Engine)
C0500 Drive lock detection by the engine firmware
C0510 High voltage remote control error
C0530 Backup task error
C0540 Engine firmware unexpected control detection
C0800 Print sequence error
C0840 RTC error ("Time for maintenance T" appears)
C0970 Power interruption detection
C1810 Paper feeder communication error (PF1)
C1820 Paper feeder communication error (PF2)
C2000 Main motor steady state error
C2010 Main motor startup error
C2600 PF feed motor error (PF1)
C2610 PF feed motor error (PF2)
C4000 Polygon motor startup error
C4010 Polygon motor steady-state error
C4201 Laser error
C6000 Broken fuser heater
C6020 Thermopile high temperature error

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
