Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-32
(4) Jam Codes
Error code Contents note
J0000 Power ON jam
J0101/J0104/J0105/
J0106
Paper jam caused by the
software factor
J0107 Fuser temperature stabiliza-
tion time-out
J0110 Right cover open detection
J0501/J0502/J0503/
J0508/J0509
No feed Note: Prior check point at no feed
J0501/J0502/J0503 Cassette no feed Condition: No mark of paper feed at the paper
leading edge and the cassette bottom plate does
not rise.
J0501 Cassette no feed Condition: No mark of paper feed at the paper
leading edge and, the cassette bottom plate is ris-
ing but the paper feed drive does not start.
J0502/J0503 Cassette no feed Condition: No mark of paper feed at the paper
leading edge and, the cassette bottom plate is ris-
ing but the paper feed drive does not start.
J0501/J0502/J0503 Cassette no feed Condition: Mark of paper feed slippage at the
paper leading edge (the pickup roller cannot con-
vey paper.)
J0501/J0502/J0503 Cassette no feed Condition: A part other than the center part of the
leading edge of the paper is broken. (Paper jam
occurs as paper is caught up before entering the
retard roller)
J0501/J0502/J0503 Cassette no feed Condition: The center part of the paper leading
edge is folded or torn (It does not reach to the
retard roller or retard roller does not rotate).
J0501 Cassette no feed Condition: The paper conveying force is lowered
and paper slips.
J0502/J0503 Cassette no feed Condition: The paper conveying force is lowered
and paper slips.
J0501 Cassette no feed Condition: The paper conveying force is lowered
and paper slips or the roller does not rotate.
J0502/J0503 Cassette no feed Condition: The paper conveying force is lowered
and paper slips or the roller does not rotate.
J0501 Cassette no feed Condition: The sensor detection is unstable.
J0502/J0503 Cassette no feed Condition: The sensor detection is unstable.
J0508 No paper feed from the
duplex section
Condition: Paper is damaged (Paper is caught
up, the paper conveying force is lowered or paper
slips).
J0508 No paper feed from the
duplex section
Condition: Paper is not damaged (The duplex
conveying drive does not rotate).

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
