Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-114
(12)Abnormal sound from inside the machine
Dirt at the developer section, Foreign object adhesion or toner aggregation
(13)Abnormal sound from inside the machine
Worn, dirt, foreign object adhesion or waste toner clogging at the drum section
2 Checking the toner
remaining amount
The agitating paddle in the
toner container is warped
or toner amount is low.
Check the toner remaining
amount and replace the toner
container if necessary.
3 Reinstalling / replacing the
toner container
The torque increases due
to the toner condensation.
Shake the toner container
enough and reinstall it. Or,
replace it.
Step Check description Assumed cause Measures Reference
1 Checking the toner supply
opening
The spring for opening and
closing of the toner supply
opening is hooked with the
other parts, or deformed.
Open and close the toner
supply opening manually to
fix the operation.
2 Cleaning the developer
unit
The shaft or the bushing of
the developer roller is dirty
or foreign objects are on
them.
Check if the developer roller
rotates. If not rotating
smoothly, clean the shaft or
the bushing of the developer
roller.
3 Replacing the developer
unit
The torque inside the
developer unit increased
due to the toner condensa-
tion, etc.
Replace the developer unit.
Step Check description Assumed cause Measures Reference
1 Executing Drum refresh Toner is not enough on the
drum.
Execute Drum refresh.
2 Checking the drum unit
and the developer unit
The drum screw does not
properly rotate.
Check if the drum screw
rotates manually. Clean it if
not smoothly rotated. If it is
locked, replace the drum unit.
3 Cleaning and applying the
grease
Foreign objects adhere to
the drum drive gear cogs
or grease is in shortage.
Clean the tooth of the drum
drive gear and apply the
grease to them.
4 Replacing the drum unit The torque inside the drum
unit increased due to the
waste toner clogging, etc.
Replace the drum unit.
Step Check description Assumed cause Measures Reference

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
