Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-111
(2) Abnormal sounds from the paper conveying section
The conveying rollers, pulleys and gears are worn down, dirty or foreign objects adhere to them
(3) Abnormal sound from the developer section
Caused by the developer unit.
(4) Abnormal sound from the document processor
The DP conveying section is worn down, dirty, not attached properly or foreign objects adhere to it
(5) Abnormal sound from the exit section
The exit section is dirty or foreign objects adhere to it
Step Check description Assumed cause Measures Reference
1 Cleaning and applying the
grease
The bushing or the gear is
dirty or foreign objects are
on them.
Clean conveying roller shafts
and gears, and apply grease.
2 Replacing the bushing The bushing is worn down. Replace the conveying roller
shafts.
2 Cleaning and applying the
grease
The drive gear is dirty or
foreign objects adhere to it.
Clean the main motor drive
gear and apply grease to it.
Step Check description Assumed cause Measures Reference
1 Checking the developer
unit
The developer unit drive is
faulty.
Check the following and cor-
rect the developer unit if nec-
essary.<br>
• Developer power leaks from
the developer unit<br>
2 Replacing the developer
unit
The developer unit is
faulty.
Replace the developer unit.
Step Check description Assumed cause Measures Reference
1 Cleaning and applying the
grease
The bushing or the gear is
dirty or foreign objects are
on them.
Clean the bushings and the
shafts of the DP conveying
roller A, B, and then apply
grease to them.
2 Replacing the bushing The bushing is worn down. Replace the bushing.
3 Cleaning and applying the
grease
The drive gear is dirty or
foreign objects adhere to it.
Clean the drive gear of the
DP feed motor, and apply
grease to it.
Step Check description Assumed cause Measures Reference
1 Cleaning and applying the
grease
The bushing or the gear is
dirty or foreign objects are
on them.
Clean the upper exit pulley
shaft and gear and apply
grease to it.

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
